• Perry 1 module time switch with riders 1IO0171
  • Perry 1 module time switch with riders 1IO0171

Perry 1 module time switch with riders 1IO0171

€27.06
Tax included

Perry time switch with the following characteristics:

  • Supply voltage 230V AC 50 - 60Hz
  • Contacts rated data 16(2) A / 250V AC
  • Max commutable power 3500 VA (for single contact)
  • Max. cable cross-section at terminals 2.5 mmq
  • 1 module

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Features:

  • Perry Series
  • Contact ratings 16(2) A / 250V AC
  • Max. number of programs (ON-OFF) 48
  • Minimum ON-OFF time 15'.
  • Displays mechanical jumper crown
  • Max section of cables at terminals 2.5 mmq
  • Degree of protection (IP) IP20 - IP30 (with cover) - IP40 (with back panel)
  • Output type captive screw terminals
  • Insulation class II
  • Power reserve max 100 hours
  • Type of rechargeable battery reserve NiCd
  • Time tolerance + - 1 sec/day
  • Operating temperature limits -10°C +50°C
  • Storage temperature -10°C +50°C
  • DIN rail / wall mounting / back panel installation type
  • Thermoplastic casing - grey RAL 7035
  • Type civil / tertiary / industrial use
  • Controls on board mechanical crown wheel - Selector: timer position / fixed ON
  • Clock setting precision mechanical with reference index
  • Mechanical key crown programming (15' blocks)
  • Dimensions (WxDxH) 17.5 x 60 x 128 mm

  • Brand
  • Reference
    PER 1IO0171
  • In stock
    154 Items
  • EAN13
    8019108031177

  • Type
    Time Switches
  • Model
    Daily
  • Installation
    Din
